Your Question:

To design a mod 10 counter using JK Flip-Flops. The clock pulse for the counter will be generated using a 555 timer as an astable multivibrator. The output must be displayed on a seven-segment display. 2.2. REFERENCE: Manufacturer’s data sheets of the HA17555 or the NE555P-TI or the LM555 555 timer IC, the 74LS47 decoder and the 74HCT112 JK Flip Flop. 2.3. IMPORTANT DESIGN FORMULA: 𝒇 = 𝟏. 𝟒𝟒 (𝑹𝟏 + 𝟐𝑹𝟐) × 𝑪𝟏 2.4. DESIGN SPECIFICATIONS: • Frequency= 10 Hz • Duty Cycle=50% • C1=10 uF 2.5. COMPONENTS: 1 x IC HA17555 or the NE555P-TI or the LM555 timer IC Couple of x LED 5 mm LEDs (1 RED color and 1 GREEN in color) Couple of x

Step By Step Answers with Explanation

To design a Mod 10 counter using JK flip-flops with clock generation using a 555 timer and display the output on a seven-segment display, you'll need several components and follow these steps:

Components:

5. Resistors (for timing)

6. Capacitors (for filtering)

1. Clock Generation using 555 Timer:

- Use the 555 timer in astable mode to generate a 10 Hz clock signal with a 50% duty cycle.

2. Mod 10 Counter using JK Flip-Flops:

- You'll need two 74HCT112 dual JK flip-flops to create a Mod 10 counter.

- J2 = K2 = Q1 (output of the first flip-flop)

- Connect the clear (CLR) inputs of both flip-flops to ground (to disable the clear function).

- Connect the outputs of the 74LS47 to the corresponding inputs of the seven-segment display.

4. Display and Indicators:

- Connect the power supply to +5V and ground.

- Ensure proper decoupling capacitors for stable operation.

7. Adjustment:

- If the counter doesn't count correctly or the clock frequency is off, adjust the resistor values in the 555 timer circuit as needed.
